IRFZ24

Power MOSFET, 60 V, 60 W, 17 A, TO-220AB

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.42~0.52 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.42~0.52

PartNumber:: IRFZ24

Brand:: International Rectifier - IR | Pack: TO | D/C: 00+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. yakenlin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-30

From Other Seller

Part Number:IRFZ24
US $0.42 - 0.52
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRFZ24 is a Power MOSFET. The IRFZ24 provides the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-220AB package of the IRFZ24 is universally preferred for all commercial-industrial applications at power dissipation levels to approximately 50 W. The low thermal resistance and low package cost of the TO-220AB contribute to its wide acceptance throughout the industry.

Parametrics

IRFZ24 absolute maximum ratings: (1)Drain-Source Voltage VDS: 60 V; (2)Gate-Source Voltage VGS: ± 20 V; (3)Continuous Drain Current VGS at 10 V: TC = 25 ℃ 17 A; TC = 100 ℃ 12 A; (4)Pulsed Drain Current IDM: 68 A; (5)Linear Derating Factor: 0.40 W/℃; (6)Single Pulse Avalanche Energyb EAS: 100 mJ; (7)Maximum Power Dissipation TC = 25 ℃ PD: 60 W; (8)Peak Diode Recovery dV/dtc dV/dt: 4.5 V/ns; (9)Operating Junction and Storage Temperature Range TJ, Tstg: - 55 to + 175℃; (10)Soldering Recommendations (Peak Temperature) for 10 s: 300℃.

Features

IRFZ24 features: (1)Dynamic dV/dt Rating; (2)175℃ Operating Temperature; (3)Fast Switching; (4)Ease of Paralleling; (5)Simple Drive Requirements; (6)Compliant to RoHS Directive 2002/95/EC.
