Product Summary

The ATMEGA8L-8AU is a 8-bit with 8kbytes in-system programmable flash. The ATMEGA8L-8AU is a low-power CMOS 8-bit microcontroller based on the AVR RISC architecture. By executing powerful instructions in a single clock cycle, the ATMEGA8L-8AU achieves throughputs approaching 1MIPS per MHz, allowing the system designer to optimize power consumption versus processing speed.

Parametrics

ATMEGA8L-8AU absolute maximum ratings: (1)AVCC Analog Supply Voltage VCC: - 0.3 to VCC + 0.3(3)V; (2)VREF Reference Voltage: 2.0 AVCC; (3)VIN Input voltage: GND VREF; (4)Input bandwidth: 38.5 kHz; (5)VINT Internal Voltage Reference: 2.3 to 2.9 V; (6)RREF Reference Input Resistance: 32 kΩ; (7)RAIN Analog Input Resistance: 55 to 100 MΩ.

Features

ATMEGA8L-8AU features: (1)High-performance, Low-power Atmel AVR 8-bit Microcontroller; (2)Advanced RISC Architecture; (3)High Endurance Non-volatile Memory segments; (4)Power-on Reset and Programmable Brown-out Detection; (5)Internal Calibrated RC Oscillator; (6)External and Internal Interrupt Sources; (7)Five Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, and Standby.

Diagrams

ATMEGA8L-8AU Clock Distribution

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ATmega8L-8AU
ATmega8L-8AU
Atmel
8-bit Microcontrollers (MCU) 8kB Flash 0.5kB EEPROM 23 I/O Pins
Data Sheet
0-1: $2.13
1-10: $1.78
10-25: $1.34
25-100: $1.21
ATMEGA8L-8AUR
ATMEGA8L-8AUR
Atmel
8-bit Microcontrollers (MCU) AVR 8KB FLSH 512B EE 1KB SRAM-8MHz
Data Sheet
0-1670: $1.22
1670-2000: $1.22
