Product Summary
The 2SC1815-Y is an NPN Silicon Epitaxial Transistor. It is for Audio Frequency General Purpose Amplifier Applications. It is complementaty to 2SA 1015.
Parametrics
2SC1815-Y absolute maximum ratings:(1)Collector-Base Voltage:60 V; (2)Collector-Emitter Voltage: 50 V; (3)Emitter-Base Voltage:5 V; (4)Collector Current: 150mA; (5)Base Current:50 mA; (6)Collector Power Dissipation: 400mW; (7)Junction Temperature: 125℃; (8)Storage Temperature:–55 to +125℃.
Features
2SC1815-Y electrical Characteristics: (1)Collector cut-off current: 0.1 μA; (2)Emitter cut-off current: 0.1 μA; (3)Collector-emitter saturation voltage: 0.25 V; (4)Base-emitter saturation voltage: 1V; (5)Transition frequency: 80MHz; (6)Collector output capacitance: 3.5pF;(7) Base intrinsic resistance:50Ω;(8) Noise figure:10dB
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 2SC1815-Y(TE2,F,T) |
Toshiba |
Transistors Bipolar (BJT) x34 Small Signal Transistor |
Data Sheet |
Negotiable |
|
||||
