MAX211ECAI

15kV ESD-Protected, 5V RS-232 Transceiver, SSOP28, low-power

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.14~2.34 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.14~2.34

PartNumber:: MAX211ECAI

Brand:: Maxim Integrated Products - Maxim | Pack: SSOP | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. yakenlin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-06

From Other Seller

Part Number:MAX211ECAI
US $2.14 - 2.34
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX211ECAI is a +5V RS-232 Transceiver. It is designed for RS-232 and V.28 communications in harsh environments. The MAX211ECAI is available in 28-pin SO packages, as well as a 28-pin SSOP that uses 60% less board space. It operates with four 0.1uF capacitors, further reducing cost and board space. The applications of the MAX211ECAI are Notebook, Subnotebook, Palmtop Computers, Battery-Powered Equipment, Hand-Held Equipment.

Parametrics

MAX211ECAI absolute maximum ratings: (1)VCC:-0.3V to +6V; (2)V+:(VCC - 0.3V) to +14V; (3)V-:-14V to +0.3V; (4)Input Voltages: T_IN:-0.3V to (V+ + 0.3V), R_IN:±30V; (5)Output Voltages: T_OUT:(V- - 0.3V) to (V+ + 0.3V), R_OUT:-0.3V to (VCC + 0.3V); (6)Short-Circuit Duration, T_OUT:Continuous; (7)Continuous Power Dissipation:762mW; (8)Operating Temperature Ranges:0℃ to +70℃; (9)Storage Temperature Range:-65℃ to +165℃; (10)Lead Temperature (soldering, 10s):+300℃.

Features

MAX211ECAI features: (1)For Low-Voltage Applications MAX3222E/MAX3232E/MAX3237E/MAX3241E/MAX3246E: ±15kV ESD-Protected Down to 10nA, +3.0V to +5.5V, Up to 1Mbps, True RS-232 Transceivers (MAX3246E Available in a UCSP Package); (2)For Low-Power Applications MAX3221/MAX3223/MAX3243: 1μA Supply Current, True +3V to +5.5V RS-232 Transceivers with Auto-Shutdown; (3)For Space-Constrained Applications MAX3233E/MAX3235E: ±15kV ESD-Protected, 1μA, 250kbps, +3.0V/+5.5V, Dual RS-232 Transceivers with Internal Capacitors; (4)For Low-Voltage or Data Cable Applications MAX3380E/MAX3381E: +2.35V to +5.5V, 1μA, 2Tx/2Rx RS-232 Transceivers with ±15kV ESD-Protected I/O and Logic Pins.
